Delivery Date:
06/17/2021
Department Name:
Wenham Fire Department
Department City / State:
Wenham, MA
Truck Type:
Sutphen Corporation – HS #6889
Dealer – Shipman’s Fire Equipment
WHEELBASE: 170”
TRAVEL HEIGHT: 9’ – 6”
TRAVEL LENGTH: 29’ – 0 ¼”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a Flat Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 18,000 lbs
- Rear Axle and Suspension 24,000 lbs
- Engine: Cummins L 9, 380 HP
- Alternator: Leece Neville, 270 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 750-Gallon Water Tank
- 20-Gallon Foam Tank
BODY: Sutphen
- Stainless Steel
- ROM Roll-Up Compartment Doors
- Over 165 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Body: S1 – STS 31/47 L60H / R45H Ladder Bracket
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper Extension
- Federal Q2B Siren, Grille Mount
- Hannay Electric Cord Reel, 150’ (1)
- Generator: 6KW Smart Power TM HYD
- Camera System: FRC, Inview Trueview, Single Camera
- Whelen Freedom 72” Lightbar
- Whelen PFH1 Brow Light
- Whelen PFH2 Tele Lights
- Whelen Traffic Advisor
