Delivery Date:
06/29/2023
Department Name:
Warren Township Fire Department
Department City / State:
South Bend, IN

Dealer –  Herb Fire

WHEELBASE: 216 ½”

TRAVEL HEIGHT: 10’ – 4”

TRAVEL LENGTH: 34′ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Waterous

  • CSU-2000 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlays: (2) 1 ½” and (1) 2 ½” w/ Liftout Tray and Rollers
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Waterous Aquis 3.0

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • Over 400 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: PA-18 RES 56/53 Ladder Through Tank & Double Hatch

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Back-Up Camera
  • Intercom System: SetCom
  • Whelen Freedom IV 72” LED Light Bar
  • FireTech 3-Piece 72” LED Brow Light
  • Command Light KL-415D-F Light Tower
  • Whelen M9 12V LED Scene Lights
