Delivery Date:
08/21/2024
Department Name:
Wallingford Fire Department
Department City / State:
Wallingford, CT

Dealer: MES-Shipman’s Fire

WHEELBASE: 224”

TRAVEL HEIGHT: 9’ – 11”

TRAVEL LENGTH: 34’ – 5 ½”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Four- Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12 455HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-XS-1500 GPM, 6” Suction Single Stage Pump
  • Discharges: (1) 2 ½” Left, (1) 2 ½” Right, (1) 4” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 1 ¾” Speedlay w/ Lift Out Tray & (1) 2 ½” Speedlay w/ Lift Out Tray
  • 750-Gallon Water Tank

BODY:                 Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll Up Compartment Doors
  • Over 460 cu. ft. of Compartment Space
  • Alco-Lite PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: PA-16 RES 56/53 Lad Under Hosebed & Double Hatch

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera
  • Whelen Freedom IV 72” LED Lightbar
  • Opticom Mounted in Lightbar
  • FireTech 3-Piece 72” LED Brow Light
  • Whelen EZM9 LED Scene Lights
