Delivery Date:
04/03/2025
Department Name:
Vienna Fire Department
Department City / State:
Pfafftown, NC
Truck Type:
Dealer – First Choice Fire and Safety
WHEELBASE: 218”
TRAVEL HEIGHT: 10’ – 4”
TRAVEL LENGTH: 34’ – 10 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10’ Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Waterous
- CSU-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (2) 2 ½” Valve 3” Pipe to Left Rear, (2) 2 ½” Valve 3” Pipe to Right Rear, (1) 2 ½” to Front Bumper, (1) Deck Gun
- Crosslay: (1) 2 ½”
- Speedlays: (2) 1 ½” w/ Liftout Trays
- 750-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- AMDOR Roll-Up Compartment Doors
- Over 220 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 1225A 35’ 3-Section & 775A 14’ Roof & 10’ Folding
- Body: PA-11 Res 54/53 Low Rgt, w/ Driver’s Side Hatch Compt, 28” H ID A1
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Bumper
- Intercom System: FireCom 5200D, Dual Radios, 5 Position
- Generator: Smart Power, 8KW
- Federal Q2B, Grille Mount
- Hannay Electric Cord Reel, 175’ (1)
- Whelen Mini 21” LED Lightbar
- FRC Spectra 12V Brow
- (3) Whelen Freedom IV 23.25” LED Lightbars
- FRC Spectra 12V Scene Light
MONITOR:
- TFT XFC-42 Crossfire w/ Safety Flow w/ Quad Stack Tip & Stream Shaper
