WHEEL BASE: 185”
TRAVEL HEIGHT: 10’-1”
TRAVEL LENGTH: 30’-10”
CHASSIS: Sutphen 62” Extended Cab with half 10” raised roof
- Four-Door, Six-Person cab
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins ISL 9, 380 HP
- Alternator: Leece Neville 270 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QFLO-1250 GPM
- Discharges: (2) 2 ½” Left, (2) 2 ½” Right, (1) 3” Deck Gun
- 20-Gallon Foam Tank
- FoamLogix 2.1
- 1500-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Rom Roll-Up Doors
- Alco-Lite PEL-24
- 193 cu. ft. total compartment space
OPTIONAL EQUIPMENT:
- Ziamatic Quic-Lift Electric Ladder Rack
- Traffic Advisor, Whelen
- Scene Light, Whelen
- 3 Camera Voyager System
- Deck Gun Monitor: TFT 1250 GPM Hurricane Electric Monitor
- 12” Bumper
- Federal E-Q2B Siren
