Delivery Date:
04/17/2024
Department Name:
Utica Fire Department
Department City / State:
Utica, NY
Truck Type:
Dealer – Vander Molen Fire Apparatus Sales and Service
WHEELBASE: 210”
TRAVEL HEIGHT: 9’ – 6 ½”
TRAVEL LENGTH: 33’ – 0 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ Flat Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Waterous
- CSU-1500 GPM, Single Stage
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (4) 2 ½” Crosslay, 2 ½” Swivel
- 750-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Hinged Compartment Doors, Painted
- Over 290 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
- Body: PA-09 RES 50/47 Ladder Chute & Hatch
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Painted
- Federal Q2B Siren, Grille Mount
- Camera System: Intec, Single Camera
- Whelen Freedom IV 72” LED Lightbar
- Whelen LED MCFLED Beacons
- FireTech 1-Piece 72” LED Brow Light
- FireTech Guardian Elite 12V Scene Lights
- FireTech Guardian Junior Scene Lights
