Delivery Date:
07/29/2020
Department Name:
Turkey Creek Fire Territory
Department City / State:
Syracuse, IN
Truck Type:
Sutphen Corporation – HS #6602
Dealer – Herb Fire
WHEELBASE: 209”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 33’ – 4”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab w/ 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1,500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right Rear, (1) 2 ½” Left Rear, (1) 2 ½” Front Left, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlay: (2) 2” w/ 1 ½” Swivel
- 1,000-Gallon Water Tank
- 25-Gallon Foam Tank
- Hale SmartFoam Foam System
BODY: Sutphen
- ROM Roll-Up Compartment Doors
- 294 Cu. Ft. Compartment Space
- Alco-Lite Ladder Package (24’ 2-Section, 14’ Roof and 10’ Folding)
- Body: G9-Alum 40/51
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless-Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview 360
- 6KW Smart Power Generator
- 3 Bottle Compartments
- HiViz 72” Brow Light
- Whelen Freedom IV Lightbar
- Whelen M9 Scene Light
- Whelen M9 Warning Lights
- Whelen 600 LED Red Lights
- FRC Spectra Telescopic Lights
