Delivery Date:
05/26/2020
Department Name:
Stittville Fire District
Department City / State:
Stittville, NY

Sutphen Corporation – HS #6567

Dealer – Vander Molen Fire Apparatus Sales and Service

WHEELBASE: 177”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 30’ – 3 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • Hinged Compartment Doors
  • Huck Bolted #304 Stainless Steel
  • 145.7 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package (24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: PS-10 Res 30/47

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • 7 Bottle Compartments
  • FRC Spectra LED Brow Light
  • Whelen Freedom IV 72” Lightbar
  • Whelen M9 LED Scene Lights
  • FRC Spectra Telelights
  • Whelen B6MM Beacons
  • Whelen Ion Warning Lights
