Delivery Date:
05/10/2023
Department Name:
Springville Fire Company
Department City / State:
Springville, PA
Truck Type:
Dealer – Signal 1 Fire Equipment
WHEELBASE: 194”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 32′ – 2 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 31,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 2” Valve-Piping, 1 ½” Swivel
- 1,000-Gallon Water Tank
BODY: Sutphen
- Huckbolted #304 Stainless Steel
- Amdor Roll-Up Compartment Doors
- Over 145 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: PS-04 Res 40/47 Electric Ladder Rack
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Single Camera
- Roto Ray Warning Light
- FRC Spectra LED Brow Light
- FRC Spectra Tele Lights
- Whelen Freedom IV 72” LED Light Bar
- Whelen M9 Scene Lights
- Whelen L31 Beacons
