Delivery Date:
10/10/2023
Department Name:
Springfield Township Fire Department
Department City / State:
Springfield Township, MI
Truck Type:
Dealer – Apollo Fire Apparatus Sales and Service
WHEELBASE: 196”
TRAVEL HEIGHT: 10’ – 2”
TRAVEL LENGTH: 32′ – 9”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front/Left of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 2” w/ 1 ½” Swivel
- 1,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- 222 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Sec & PRL-14 14’ Roof & 10’ Folding
- Body: G2 – Alum 40/51 Ladder Chute
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Single Camera
- Triple Air Bottle Compartments
- Whelen PFH2 LED Brow Light
- Whelen Freedom LED Lightbar
- Command Light
