Delivery Date:
01/14/2025
Department Name:
Springfield Fire Department
Department City / State:
Springfield, OH

Dealer – Heritage Fire Equipment

WHEELBASE: 188”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 31’ – 10”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 73” Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 19,000 lbs w/ (3) 56” Leafs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper w/ 2” Plumbing, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Elkhart w/ Flush

BODY:                 Sutphen

  • 3/16” Extruded Aluminum
  • AMDOR Compartment Doors
  • Nearly 230 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
  • Body: S1 – Alum 31/53 RGT Low Lad Brkt

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera (Wired)
  • FRC Spectra 12V LED Scene Lights (2)
  • FireTech 12V LED Hosebed Lights
  • FRC Spectra 12V LED Brow Lights
  • Whelen Freedom IV 72” LED Light Bar
  • Whelen L31 Rear Beacons
