Delivery Date:
08/15/2017
Department Name:
Southington Fire Department
Department City / State:
Southington, CT
Truck Type:
WHEEL BASE: 214”
TRAVEL HEIGHT: 10’-2”
TRAVEL LENGTH: 33’-8”
CHASSIS: Sutphen 73” extended cab with half 10” raised roof
- Four-Door, Six-Person Cab
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-1500 GPM
- Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 750-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Amdor Roll-Up Doors
- 237 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package, PEL-28
OPTIONAL EQUIPMENT:
- 6 KW Smart Power Generator
- Hannay Electric Cord Reel, 200’
- Ziamatic Quic-Lift Electric Ladder Rack
- Traffic Advisor, Whelen
- Whelen Pioneer Telelight, Flood/Spot Light
- Warning Lights, Whelen
- Camera System, Voyager 3
- Federal Q2B
- 18” Extreme Duty Steel Bumper
- Roto-Ray
