Delivery Date:
12/05/2023
Department Name:
Scott Township VFD
Department City / State:
New Castle, PA
Truck Type:
Dealer: FAST of the Allegheny Mountains
WHEELBASE: 238”
TRAVEL HEIGHT: 10’ – 8”
TRAVEL LENGTH: 36′ – 3”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with 15” Raised Roof
- Four-Door, Six-Person Cab
- 13” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension: 23,000 lbs.
- Rear Axle and Suspension: 31,000 lbs.
- Engine: Cummins X12, 500HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharge: (1) 3” Left, (1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Speedlays: (2) 2” 1 ½” Swivel
- 1,200-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- 320 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: G9 – Alum 40/51 Ladders Through Tank
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC Inview Trueview, Single Camera
- Inverter: MasterVolt Combimaster 3000 Watt
- Roto Ray Warning Light
- Will-Burt Light Tower
- (2) FireTech FT-MB-2.15-FT
- Whelen Freedom LED Lightbar
- FireTech Guardian Elite
