Delivery Date:
03/29/2023
Department Name:
Sandusky Fire Department
Department City / State:
Sandusky, OH

Dealer –  Herb Fire

WHEELBASE: 196”

TRAVEL HEIGHT: 10’ – 4”

TRAVEL LENGTH: 32′ – 3”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins X 12, 500HP
  • Alternator: Delco-Remy 430 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

  • QMAX XS 1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (1) 2 ½”
  • Speedlays: (2) 2” w/ Swivels & Poly Lift-Out Trays
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • 245 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: G9 – Alum 40/51 Ladders Through Tank

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera
  • Intercom: SetCom
  • HI-VIZ 72” Brow Light
  • Triple Air Bottle Compartments (3)
  • Whelen M9 Scene Lights
  • FRC Spectra LED Scene
  • Light Tower: Command Light KL-415D 12V
