Delivery Date:
03/15/2021
Department Name:
Salem Fire Department
Department City / State:
Salem, OH
Truck Type:
Sutphen Corporation – HS # 6785
Dealer – Herb Fire
WHEELBASE: 196”
TRAVEL HEIGHT: 10’
TRAVEL LENGTH: 32’-8”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” extended cab with 10” raised roof
- Four-Door, Four-Person Cab
- 10” Double Rails, Single Axle (110K PSI)
- Front Suspension 20,000 lbs.
- Rear Suspension 27,000lbs.
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- XS QMAX-2,000 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper w/ 2 ½” Plumbing, (1) 3” Deck Gun
- Crosslays: (1) 2 ½” w/ Swivels and Poly Lift-Out Trays
- Speedlays: (2) 2” w/ Swivels and Poly Lift-Out Trays
- 1000-Gallon Water Tank
- 20 Gallon Foam Tank
BODY: Sutphen
- Aluminum 40/51
- ROM Roll-Up Compartment Doors Painted
- 294 cu. ft. Total Compartment Space
- Body: Custom Pumper G9
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless-Steel Bumper
- Federal Q2B Siren, Grille Mount
- Whelen Freedom LED Light Bar
- Firetech Spectra Brow Light
- Whelen 900 Red LED
- Will-Burt Light Tower
