Delivery Date:
07/19/2023
Department Name:
Rome Fire Department
Department City / State:
Rome, NY
Truck Type:
Dealer – Vander Molen Fire Apparatus Sales and Service
WHEELBASE: 175”
TRAVEL HEIGHT: 10’ – 1”
TRAVEL LENGTH: 29′ – 7 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 56” cab with a Flat Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Left Rear, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed, 3” Deck Gun
- Crosslays: (2) 2” w/ 1 ½” Swivel
- 980-Gallon Water Tank
- 20-Gallon Foam Tank
- Foam System: Hale Smartfom 2.1 A
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Hinged Compartment Doors
- Over 155 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-Sec & 775A 14’ Roof & 10’ Folding
- Body: PS-11 RES 40/47 Low Right (BRKT/Elec Rack)
ADDITIONAL EQUIPMENT:
- 12” Polished Stainless Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Whelen 72” Freedom Light Bar
- Whelen Arges Scene Light
- Whelen Micro Freedom Beacons
- FireTech 3-Piece Brow Light
- FireTech Guardian Elite Scene Lights
