Delivery Date:
01/01/2021
Department Name:
Point Pleasant Borough Fire Department
Department City / State:
Point Pleasant, NJ

Sutphen Corporation – HS #6677

Dealer – Blaze Emergency Equipment Company

WHEELBASE: 194”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 32’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails, Domex (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: C.E. Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Waterous

  • CMU-2000 GPM Two Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 3” Pipe to Left Rear, (1) 3” Pipe to Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • Monitor: TFT Hurricane, Electric 1250 GPM
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Hinged Compartment Doors
  • Over 170 cu. ft. Total Compartment Space
  • Body: PA-01 Res 30/53 Electric Ladder Rack

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Ziamatic Quic-Lift Electric Ladder Rack
  • High Rise Pack Compartment
  • Booster Reel w/ 150’ of 1” Hose, Nozzle and Mount
  • Camera System: FRC, Inview Trueview, Two Cameras
  • Whelen (3) Freedom Lightbars
  • Whelen 36” Traffic Advisor
  • FR Spectra Brow Light
  • FR Spectra (2) Scene Lights
  • FR Spectra (2) 900 Scene Lights
