Delivery Date:
03/24/2025
Department Name:
Peachtree City Fire Department
Department City / State:
Peachtree City, GA

Dealer – Williams Fire Apparatus

WHEELBASE: 174”

TRAVEL HEIGHT: 10’ – 3 ”

TRAVEL LENGTH: 31’ – 2”

CHASSIS:           Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX XS 1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” w 4” Outlet, Right, (1) 2 ½” Right, (1) Front/ Left of Main Hosebed, (1) Front/ Right of Main Hosebed, (1) 2 ½” to Front Bumper, (1) 3” Deck Gun
  • Speedlays: (2) 1 ½” w/ Liftout Tray
  • 750-Gallon Water Tank

BODY:                 Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • Over 250 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
  • Body: PA-01 Res 31/53 Low Right (Elec Rack/ Brackets)

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade, Two Cameras (Wired)
  • Whelen Freedom 8 LED Lightbar
  • Whelen PFP2 12V LED Brow
  • Whelen Mini Edge LED
  • Whelen PCPSM1C 12V LED Scene
