Delivery Date:
10/23/2020
Department Name:
Parma Fire Department
Department City / State:
Parma, Ohio
Truck Type:
Sutphen Corporation – HS #6691-92
Dealer – Herb Fire Equipment
WHEELBASE: 196”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 32’ – 9”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails, Domex (110K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 24,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Hale
- QFLO-1250 Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 1 ½” & (1) 2 ½” w/ Swivels
- 500-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll Up Compartment Doors
- Over 220 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Ladder Chute w/ Backboard Storage
- Body: G2-Alum 40/51 Ladder Chute
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel Bumper Extension
- Federal Q2B Siren, Grille Mount
- Air Bottle Storage (4)
- Little Giant Ladder Mounted
- Whelen Freedom LED Lightbar
- Whelen PFH1 12V Telescopic Lights
- Whelen 900 Scene Lights
