Delivery Date:
09/12/2017
Department Name:
Palm Beach County Fire Rescue
Department City / State:
West Palm Beach, FL

WHEEL BASE: 208”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 34’

CHASSIS:              Sutphen extended cab with half 10” raised roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins ISL 9, 450 HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Hale Foamlogix 5.0

BODY:                   Sutphen

  • Aluminum
  • Hinged Compartment Doors
  • Alco-Lite PEL-24
  • 257 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Hannay Booster Reel w/ 150’
  • Combo Scene/ Warning Light, Whelen
  • Federal Q2B
  • 24” Bumper
  • Rear Vision Camera
  • Extinguisher Rack
