Department Name:
Orange Township Fire Department
Department City / State:
Lewis Center, Ohio
Truck Type:
WHEEL BASE: 241”
TRAVEL HEIGHT: 11’-3”
TRAVEL LENGTH: 37’-3”
CHASSIS: Sutphen 62” extended cab with half 15” raised roof
- Four-Door, Five-Person Cab
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins ISX 12, 500 HP
- Alternator: Niehoff, 430
- Transmission: Allison Gen 5, EVS4000R w/ retarder
PUMP: Waterous
- CSU-2000 GPM
- Discharge: (2) 2 ½” Left, (2) 3” Right, (1) 1 ½” Left, (1) 3” Left Rear, (1) 3” Right Rear, (1) 3” Front Left, (1) 2 ½” Front Bumper, (1) 1 ½” Front Bumper, (1) 3” Deck Gun,
- 30-Gallon Foam Tank
- Waterous Advantus 6 Foam System
- 750-Gallon Water Tank
BODY: Sutphen
- Stainless Steel
- Amdor Roll-Up Compartment Doors
- 1 cu. ft. Total Compartment Space
- Alco-Lite PEL-24
- Ladder Chute
OPTIONAL EQUIPMENT:
- 15KW Smart Power Generator
- Hannay Electric Cord Reel, 200’ (2)
- Traffic Advisor, Whelen
- Whelen Dominator above Grille
- Fire Research, InView 360 Camera System
- 30” Bumper
- Federal Q2B
