Custom Pumper – North Greenbush Fire District No. 1, NY

Sutphen Corporation – HS #6857

Dealer – Vander Molen Fire Apparatus

WHEELBASE: 195”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 31’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

• Four-Door, Six-Person Cab
• 10” Double Domex Frame Rails (110K PSI)
• Front Axle and Suspension 23,000 lbs
• Rear Axle and Suspension 27,000 lbs
• Engine: Cummins L 9, 450 HP
• Alternator: Leece Neville, 420 AMP
• Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

• QMAX-2000 GPM, Single Stage Pump
• Discharges: (1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (2) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
• Crosslay: (2) 2” Vale-Piping 1 ½” Swivel
• 1,000-Gallon Water Tank

BODY:                  Sutphen

• 3/16” Extruded Aluminum
• Amdor Roll-Up Compartment Doors
• 154 cu. ft. Total Compartment Space
• Duo-Safety Ladder Package (900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding)
• Body: PA-11 RED 30/53 Low Right, Electric Rack

ADDITIONAL EQUIPMENT:

• 18” Polished Stainless Steel Bumper Extension
• Federal Q2B Siren, Grille Mount
• Camera System: Brigade, Three Camera
• Pike Pole Storage Tubes, Officer Side (3)
• Whelen 81” Rota-Beam Lightbar
• Whelen PFH2 Recessed Scene Lights (2)
• Whelen PFP2 Scene Lights (4)
• Whelen 36” Traffice Advisor
• Fire Tech 72” Brow Light
