Delivery Date:
11/09/2023
Department Name:
North Greece Fire District
Department City / State:
Rochester, NY
Truck Type:
Dealer – Herb Fire
WHEELBASE: 198”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 32′ – 3 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 21,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 400HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Waterous
- CSU-2000 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe Right Rear, (3) 2 ½” Front/Left of Main Hose Bed, (1) 2 ½” Bumper, (1) 3” Deck Gun
- Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
- 750-Gallon Water Tank
- 40-Gallon Foam Tank
- Foam System: FoamPro 2002, 5.0 GPM
BODY: Sutphen
- HuckBolted #304 Stainless Steel
- Hinged Compartment Doors
- 183 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-Sec & 775A 14’ Roof & 10’ Folding
- Body: PS-11 Red 40/47 Low Right (BRKT/ELEC RACK)
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Hannay Electric Cord Reel, 150’ (1)
- Generator: Harrison, 6KW HYD
- Camera System: FRC, Inview Trueview, Single Camera
- Whelen Freedom IV 23” LED Light Bars (3)
- Opticom Mounted Stand-Alone
- FRC Spectra LED Brow Lights (2)
- Roto Ray Warning Light
- Whelen Perimeter Angled White Light
