Delivery Date:
08/03/2020
Department Name:
Newberry City Fire
Department City / State:
Newberry, SC
Truck Type:
Sutphen Corporation – HS #6697
Dealer – Williams Fire Apparatus
WHEELBASE: 185”
TRAVEL HEIGHT: 10’ – 1”
TRAVEL LENGTH: 32’
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2,000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Right, (1) 2 ½” Front Left, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 1,000-Gallon Water Tank
- 30-Gallon Foam Tank
- Akron Foam System
BODY: Sutphen
- ROM Roll-Up and Hinged Compartment Doors
- 246 Cu. Ft. Base Compartment Space
- Ladder Package (24’ 2-Section, 14’ Roof and 10’ Folding)
- Enclosed Ladder Chute
- Body: G9-Alum 40/51
ADDITIONAL EQUIPMENT:
- 30” Formed Steel Channel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview
- 3 Bottle Compartments
- Whelen Freedom IV 72” LED Lightbar
- Whelen 900 LED Scene Light
- Whelen 900 LED Warning Lights
- Whelen 700 LED Red Lights
- FRC Spectra Telelights
- Whelen Ion LED Red Lights
