Delivery Date:
11/19/2020
Department Name:
New Bern Fire Department
Department City / State:
New Bern, NC

Sutphen Corporation – HS #6611

Dealer – Stevens Fire Equipment

WHEELBASE: 201”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 33’ – 5”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” raised roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlays: (2) 1 ½” w/ Rollout Trays
  • Monitor, Akron 3431 Apollo High Rise
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Hinged Compartment Doors
  • Over 290 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package (900A 24’ 2-Section & 775A 14’ Roof Double Hooks & 10’ Folding)
  • Body: PA-19 – RES 43/53 Ladder Chute Through Water Tank

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade, Two Camera
  • Intercom: Firecom 5100D, Single Radio, 1 Position
  • Whelen Freedom IV 72” LED Light Bar
  • Whelen PCH2 12V LED Brow Light
  • Whelen M6 Red LED
  • FR Spectra 12V Tele
