Delivery Date:
01/20/2022
Department Name:
Morton-Rutledge Fire Company
Department City / State:
Morton, PA
Truck Type:
Sutphen Corporation – HS #6971
Dealer – Signal 1 Fire Equipment
WHEELBASE: 178”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 30’ – 11 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Half Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 19,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (2) 2” Pipe to Left Rear, (1) 2” Pipe to Right Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 750-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- 136 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
- Body: PA-09 – RES 31/53 Low Right
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless-Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Single Camera
- Pike Pole Storage Tubes (4)
- Whelen 72” Freedom LED Lightbar
- Opticom Mounted in Lightbar
- FireTech 1-Piece 72” LED Brow Light
- FRC Spectra Max 28K Lumens, LED 12V
- 30” FireTech MB2.27-FT-B 12V Scene Light
- FireTech Work Lights 12V
