Delivery Date:
04/13/2022
Department Name:
Morehead Fire Department
Department City / State:
Morehead, KY

Sutphen Corporation – HS #6907

Dealer – Heritage Fire Equipment

WHEELBASE: 181 – 0 ½”

TRAVEL HEIGHT: 9’ – 11”

TRAVEL LENGTH: 30′ – 10 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab with Flat Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 24,000 lbs.
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

  • QMAX-1500 GPM Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 3” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Compartment Doors
  • 170 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Compliment: 900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding
  • Body: PA-08 RES 36/48 MID Right – Electric Ladder Rack

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel, Bumper
  • Federal Q2B Siren, Grille Mount
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Camera System: Voyager 3, Split Screen
  • Whelen Freedom IV 72” LED Lightbar
  • Whelen MCFLED2 Red Beacon
  • FR Spectra 12V Brow
  • FR Spectra 12V Tele
  • FireTech 12V Scene
  • FireTech Work Light
