Delivery Date:
03/05/2024
Department Name:
Middleport Fire Department
Department City / State:
Middleport, NY
Truck Type:
Dealer – Herb Fire
WHEELBASE: 205”
TRAVEL HEIGHT: 10’ – 3”
TRAVEL LENGTH: 31’ – 8”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ a 15” Raise Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 31,000 lbs Leaf
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX XS-1750 GPM, Single Stage Pump
- Discharges: (1) 3” Left, (1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Pipe to Left Rear (1) 2 ½” Front Bumper & (1) 3” Deck Gun
- Crosslays: (1) 2 ½”
- Speedlays: (3) 1 ½”
- 1,000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: Hale SmartFoam 3.3
BODY: Sutphen
- Huckbolted #304 Stainless Steel
- AMDOR Roll-Up Compartment Door
- Over 150 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14′ Roof & 10′ Folding
- Body: PS-05 RES 40/47 Ladder Chute
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Single Camera
- TFT Crossfire Deck Gun
- Whelen 72” Freedom Lightbar
- Whelen 36” Traffic Advisor
- FireTech Guardian Scene Lights
- FireTech 3PC Brow Light
