Custom Pumper – Middlefield Fire Department, OH

WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 31’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof

• Four-Door, Four-Person Cab
• 10” Double Frame Rails (50K PSI)
• Front Axle and Suspension 20,000 lbs
• Rear Axle and Suspension 27,000 lbs
• Engine: Cummins L 9, 450HP
• Alternator: Leece Neville, 350 AMP
• Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

• QMAX-1500 GPM
• Discharges: (1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Left Rear,
• 1 ½” Front Bumper, (1) 3” Deck Gun
• Crosslay: (1) 2 ½” and (2) 2” Speedlays with 1 ½” Swivel and Poly Lift-Out Tray
• 30-Gallon Foam Tank
• 1000-Gallon Water Tank

BODY:                  Sutphen

• 3/16” Extruded Aluminum
• Rom Roll-Up Compartment Doors
• Ladder Chute
• 314 cu. ft. of Total Compartment Space
• Alco-Lite Ladders (24’ 2-Section, 14’ Roof and 10’ Folding)

OPTIONAL EQUIPMENT:

• 24” Bumper Extensions
• Federal Q2B Siren
• Hannay Electric Cord Reel, 150’ (1)
• Harrison 8kw Generator
• FRC inView TrueSight, Camera System
• Akron Revel 12v, Scene Light
• Stokes Storage
• Brow Light, 12v LED, Firetech 3-Part 72”
