Department Name:
Allen Township Fire Department
Department City / State:
Marysville, OH
Truck Type:
WHEEL BASE: 185”
TRAVEL HEIGHT: 9’-8”
TRAVEL LENGTH: 32’-1”
CHASSIS: Sutphen 62” extended cab with half 10” raised roof
- Four-Door, Four-Person Cab
- Front Axle and Suspension 19,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins ISL 9, 450 HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- 30-Gallon Foam Tank
- FoamLogix 2.1
- 1000-Gallon Water Tank
BODY: Sutphen
- Aluminum
- Rom Roll-Up Doors
- 222 cu. ft. Total Compartment Space
- Alco-Lite PEL-24
- Ladder Chute w/ Backboard Storage
OPTIONAL EQUIPMENT:
- 10KW Smart Power Generator
- Hannay Electric Cord Reel, 150’
- 24” Bumper
- Federal Q2B
- Scene Lights, Whelen
- Warning Lights, Whelen
- Camera System, Safety Vision SV-CLCD0-70
- Light Tower, Command Light Knight KL450, 3000W
