Delivery Date:
09/21/2022
Department Name:
Madison Township Fire Department
Department City / State:
Madison Township, Ohio
Truck Type:
Sutphen Corporation – HS #7157
Dealer – Heritage Fire Equipment
WHEELBASE: 196”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 32′ – 2”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with 10” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 24,000 lbs.
- Engine: Cummins X 12, 500HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Waterous
- CSU-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (2) 2” w/ 1 ½” Swivel
- 750 -Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- 216 cu. ft. Total Compartment Space
- Body: S2 – Alum 43/53 Ladder Chute
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC Inview Trueview
- Intercom System: David Clark 5-Position
- Whelen Freedom IV 72” LED Light Bar
- Whelen M6 Warning Lights
- FireTech 3-Piece 72” LED Brow Light
- FireTech Guardian Elite Scene Lights
- FireTech Tele Lights
- FireTech 33” Mini Brow Light
