Delivery Date:
02/26/2022
Department Name:
Lodi Fire Department
Department City / State:
Lodi, OH
Truck Type:
Sutphen Corporation – HS #6983
Dealer – Herb Fire
WHEELBASE: 209”
TRAVEL HEIGHT: 10”
TRAVEL LENGTH: 32”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 19,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Hale
- QMAX 1500 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 3” Deck Gun
- Speedlay: (2) 2” w/ 1 ½” Swivel, (1) 2 ½“ w/ 2 ½“ Swivel
- 1,500-Gallon Water Tank
- 20-Gallon Foam Tank
- Foam System: Akron 125 GPM External
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-up Painted Compartment Doors
- 186 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Ziamatic Quic-Lift Electric Ladder Rack
- Ladder Chute w/ Suction Hose Storage
- Body: G7 – Aluminum 40/51 Electric Ladder Rack
ADDITIONAL EQUIPMENT:
- 6” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Alco-Lite 8ft Roof Ladder
- Camera System: FRC, Inview Trueview, Single Camera
- FT-MB-2.18-FT-W Brow Light
- Whelen Freedom 72” LED Lightbar
- Whelen 600 Quad Taillights
- Firetech 12v LED Scene Lights
- Whelen LED TAL65 36” Traffic Advisor
