Delivery Date:
09/08/2018
Department Name:
Lexington Fire Department
Department City / State:
Lexington, SC
Truck Type:
WHEEL BASE: 190”
TRAVEL HEIGHT: 10’ – 3”
TRAVEL LENGTH: 31’ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Dorr, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins ISL 9, 450HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
Pump: Hale
- QMAX-1500 GPM
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2” Front Bumper, (1) 3” Deck Gun
- Crosslay: (1) 2 ½” and (2) 2” Speedlays with 1 ½” Swivel and Poly Lift-Out Tray
- 20-Gallon Foam Tank
- Waterous Aquis 3 Foam System
- 1000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Hansen Roll-Up Doors
- 266 cu. ft. Total Compartment Space
- Duo-Safety Ladders (28’ 2-Section, 16’ Double Hook Rood and 10’ Folding)
OPTIONAL EQUIPMENT:
- 24” Bumper Extension, 2” Raised Lid, and Full-Width, Deep-Center Trough
- Voyager 2, Camera System
- Whelen 295HFSA7 Electric Siren
- Ziamatic Hydraulic Ladder Rack
- Federal Q2B Siren
- Whelen 600 Super LED Warning Lights
- Whelen LED TAL65 Traffic Advisor
- Whelen M9, LED, Surface Mount Scene Lights
