Dealer – Herb Fire
WHEELBASE: 187”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 31’ – 6”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Single Domex Frame Rails, Single Axle (110K PSI)
- Front Axle and Suspension 19,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9 450 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-XS-1500 GPM Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½ Left Rear, (1) 2 ½ Front/Right of Main Hosebed, (1) 1 ½ Front Bumper, (1) 3” Deck Gun
- 1000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll Up Compartment Doors
- Alco-Lite Ladder Package: PEL-24 24’2 2-Section & PRL-14’14 Roof & 10’ Folding
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Inview, Two Cameras
- Whelen Freedom LED Light Bar
- Hi-Viz 72” Brow Light
- Whelen M9 Warning Red LED
- FRC Spectra 20K Tele-Lights
- Whelen LED Traffic Advisor
