Delivery Date:
03/25/2020
Department Name:
Leipsic Fire Department
Department City / State:
Leipsic, OH
Truck Type:
WHEEL BASE: 234”
TRAVEL HEIGHT: 10’
TRAVEL LENGTH: 33’ – 2”
CHASSIS: Int’l HV607 – 4DR
- Four-Door, Five-Person Cab
- Front Axle and Suspension 14,000 lbs
- Rear Axle and Suspension 26,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 325 AMP
- Transmission: EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (1) 2” w/ Swivel, (2) 1 ½”
- 1,000-Gallon Water Tank
BODY: Sutphen
- AMDOR Roll-up Compartment Doors
- 222 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Ladder Chute: Enclosed
- Body: C2 –43/53 Ladder Chute
ADDITIONAL EQUIPMENT:
- 20” Stainless Steel bumper, Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Inview Trueview, Rear View
- Air Bottle Compartments: 4
- Whelen Freedom Lightbar
- Whelen M9 Scene Lights
- Whelen MCFLED2 Beacon LED Lights
