Delivery Date:
06/25/2022
Department Name:
Emerald - Mound Lebanon Fire Protection
Department City / State:
Lebanon, IL
Truck Type:
Sutphen Corporation – HS #7093
Dealer – Cashion Fire Equipment
WHEELBASE: 215”
TRAVEL HEIGHT: 10’
TRAVEL LENGTH: 33’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 18,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 400HP
- Alternator: Leece Neville, 270 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right w/ 4” Outlet, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlays: (2) 2” w/ 1 ½” Swivels
- 1000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: Foampro 2002, 5.0 GPM
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors, Painted
- Over 246 cu ft. Total Compartment Space
- Alco-Lite Pel-24 Ladder Package: 24’ 2-section & PRL-14, 14’ Roof & 10’ Folding
- Body: G9 – Alum 40/51 Ladders Thru Tank
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel, 10” Tall, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Generator: 6KW SmartPower
- Hannay Electric Cord Reel, 150’ (1)
- Federal Signal Allegiant LED Lightbar
- HIVIZ 72” Brow Light
- FireTech Guardian Elite Scene Light
- FireTech LED Work Lights
