Delivery Date:
05/17/2023
Department Name:
Laurence Harbor Fire Company
Department City / State:
Laurence Harbor, NJ
Truck Type:
Dealer – Blaze Emergency Equipment Company
WHEELBASE: 185”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 30′ – 9 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension: 19,000 lbs.
- Rear Axle and Suspension: 24,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 4” Deck Gun
- Crosslays: (2) 1 ½” & (1) 2 ½” w/ Swivels
- 750-Gallon Water Tank
- 40-Gallon Foam Tank
- Foam System: Akron 95 GPM 3096 Internal Eductor
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors
- Over 275 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: S9 – Alum 43/53 Ladder through the Tank
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Generator: Smart Power 10KW
- Hannay Electric Cord Reel, 150’ (1)
- TFT Monsoon Electric Deck Gun
- Camera System: Brigade, Backeye 360
- Whelen Freedom IV 72” LED Light Bar
- FireTech 3-Piece 72” LED Brow Light
- FireTech Guardian Scene Lights (8)
