Delivery Date:
09/08/2018
Department Name:
Jasper Fire Department
Department City / State:
Jasper, GA
Truck Type:
WHEEL BASE: 185”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 31’ – 7”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1750 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (2) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (1) 2 ½” and (2) 2” Speedlays with 1 ½” Swivel
- 20-Gallon Foam Tank
- Hale Foamlogix 2.1
- 750-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Doors
- 3 cu. ft. Total Compartment Space
- Alco-Lite Ladders (24’ 2-Section, 14’ Roof and 10’ Folding)
- Ladder Chute with Backboard Storage
OPTIONAL EQUIPMENT:
- 18” Bumper Extension
- Smart Power 6kw Generator
- Federal Q2B
- Voyager 2, Camera System
- Hannay Electric Cord Reel, 150’ (1)
- Pike Pole Storage Tubes (3)
