Delivery Date:
11/19/2020
Department Name:
Imperial Volunteer Fire Department
Department City / State:
Imperial, PA
Truck Type:
Sutphen Corporation – HS #6634
Dealer – F.A.S.T. of the Allegheny Mountains
WHEELBASE: 237 ¼”
TRAVEL HEIGHT: 10’ – 7”
TRAVEL LENGTH: 35’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 15” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 23,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Waterous
- CSU-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlay: (2) 1 ½” w/ Liftout Tray and (1) 2 ½” Speedlay w/ Liftout Tray
- Monitor: Elkhart 8393 Stingray Manual
- 1,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Hinged Compartment Doors
- Over 640 Cu. Ft. Compartment Space
- Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
- Body: PA-16 Res 56/53 Ladder Under Hosebed and Double Hatch
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Hannay Electric Cord Reel, 200’ (1)
- Camera System: FRC, Inview Trueview, Single Camera
- Whelen Freedom 72” Lightbar
- Whelen 900 Warning Lights
- Whelen 36” Traffic Advisor
- HiViz Guardian Elite Scene Lights
- HiViz 72” Brow Light w/ Marker Lights
