Delivery Date:
11/17/2021
Department Name:
Herring Volunteer Fire Department
Department City / State:
Clinton, NC

Sutphen Corporation – HS #6874

Dealer – Stevens Fire Equipment

WHEELBASE: 173 ½”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 30’ – 7 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Half Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 240 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: S4 – Alum 31/53 Electric Ladder Rack

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel, Painted
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC Inview Trueview, Two Cameras
  • Hannay Electric Cord Reel, 150’ (1)
  • Generator: Smart Power 6KW
  • Newton 10 x 10 Electric Dump Valve, STS, Rear, w/ 4036 Manual Extension Chute
  • Whelen Freedom IV 44” LED Light Bar
  • FireTech 65” 12V LED Brow Light
  • FireTech FT-MB-2.27-FT-B 12V Scene Lights
  • FireTech Work Lights
