Delivery Date:
10/12/2018
Department Name:
Grace Chapel Fire Department
Department City / State:
Grace Chapel, NC
Truck Type:
Sutphen Corporation – HS #5901
Dealer – Stevens Fire Equipment
WHEEL BASE: 202”
TRAVEL HEIGHT: 10’ – 6”
TRAVEL LENGTH: 33’ – 2”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Niehoff, 360 AMP
- Transmission: Allison Gen 5, EVS 3000
PUMP: Waterous
- CSU-2000 GPM Single Stage
- Discharges: (2) 1 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Pipe to Left Rear, (1) 2 ½” Pipe Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlay: (3) 1 ½” with Lift Out Trays
- 1,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll Up Compartment Doors
- Duo-Safety (24’ 900A, 14’ 775-DR, 10’ 585-A)
OPTIONAL EQUIPMENT:
- Ziamatic Hydraulic Ladder Rack
- 24” Bumper Extension
- Safety Vision SV-CLCD0-70 Camera System
- Federal Q2B
- Whelen Freedom IV 72” LED Light Bar
- Whelen Warning Light
- FR Spectra LED, Brow 15K Lumens, 12V
