Delivery Date:
02/15/2019
Department Name:
Franklin Fire Department
Department City / State:
Franklin, NJ

Sutphen Corporation – HS #6236

Dealer – Signal 1 Fire

WHEEL BASE: 211”

TRAVEL HEIGHT: 9’ – 5 ¼”

TRAVEL LENGTH: 33’

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a Flat Roof

  • Four-Door, Eight-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1750 GPM, Single Stage
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Pipe Right Rear, (1) 3” Deck Gun
  • 750-Gallon Water Tank
  • Monitor: Akron 3431 Apollo High Rise
  • Crosslay: (2) 1 ½” Speedlay w/ Liftout Trays & (1) 2 ½” Crosslay

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Doors
  • Over 285 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24 (24’ 2-Section & PRL-14; 14’ Roof & 10’ Folding)

OPTIONAL EQUIPMENT:

  • 6KW Smart Power Generator
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Hannay Electric Cord Reel, 175’ (2)
  • Safety Vision SV-CLCD0-70, Camera System
  • FRC Spectra Brow
  • Whelen FN72QLED Lightbar
  • Roto-Ray LED
  • Federal Q2B
  • (2) FR Focus Tele Lights
