Delivery Date:
07/19/2021
Department Name:
Elyria Fire Department
Department City / State:
Elyria, OH
Truck Type:
Sutphen Corporation – HS #6825
Dealer – Herb Fire
WHEELBASE: 196”
TRAVEL HEIGHT: 10’ – 1”
TRAVEL LENGTH: 32’ – 7”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 15” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (110K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins X 12 455HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS 4000
PUMP: Hale
- XS QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Speedlay: (2) 2” w/ 1 ½” Swivels & Poly Lift-Out Trays
- 1000 Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-up compartment doors, Painted
- Over 233 cu. ft. Total Compartment Space
- Duo-safety Ladder package: 900A 24’ 2-Section, 775A 14’ Roof, 585A 10’ Folding
- Ladder chute with backboard storage
- Body: S2 – Aluminum 43/53 Ladder Chute
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Channel Bumper, Painted
- Federal Q2B Siren, Grille Mount
- Camera: FRC Inview Trueview Single Camera
- FRC Spectra 12V LED Brow Light
- Three Whelen Freedom 24” Led Lightbars
- FRC Spectra Scene Light
- Whelen M9V2 LEDs
- Whelen L31 Rear Beacons
