Delivery Date:
06/15/2021
Department Name:
Eden Fire Department
Department City / State:
Eden, NC

Sutphen Corporation – HS #6818

Dealer – Stevens Fire Equipment

WHEELBASE: 185”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 31′ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62”cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 31,000 lbs.
  • Engine: Cummins L 9, 380HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM, 6” Suction Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivels
  • 1,800-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • Amdor Roll-Up Compartment Doors
  • 132 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Body: G-5 with Electric Ladder Rack

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • EJ Metal 8” Dump Valve with Stainless Steel Chute to Rear
  • Camera System: FRC Inview Trueview
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Triple Air Bottle Compartments (3)
  • Whelen Freedom LED Lightbar
  • HiViz 72” Brow Light
  • FireTech Guardian Elite LED Scene Light
