Delivery Date:
05/28/2020
Department Name:
Eastlake Fire department
Department City / State:
Eastlake, OH

Sutphen Corporation – HS #6553

Dealer – Herb Fire

WHEELBASE: 226”

TRAVEL HEIGHT: 10’ – 2”

TRAVEL LENGTH: 34’ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlay: (2) 2” w/ 1 ½” Swivel
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 270 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Fully enclosed ladder chute
  • Body: G2 – Alum 40/51 Lad Chute

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel
  • Federal Q2B Siren, Grille Mount
  • 4 Bottle Compartments (3 triple, 1 single)
  • FRC Inview Trueview Camera System
  • FR Spectra LED Brow Light
  • Whelen Freedom IV 72” LED Lightbar
  • Whelen Ion LED Red Light
  • Whelen M9V2 LED Warning Light
  • Whelen 600 Super LED Warning Light
  • Whelen M6 LED Warning Light
