More Recent Deliveries

Delivery Date:
12/12/2019
Department Name:
Durham County Fire Rescue
Department City / State:
Durham, NC

Sutphen Corporation – HS #6214-15

Dealer – Stevens Fire Equipment

WHEEL BASE: 173”

TRAVEL HEIGHT: 9’-8”

TRAVEL LENGTH: 30’-1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 270 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2” Front/Left Hosebed, (1) 3” Deck Gun
  • Deck Gun Monitor: Elkhart 8297 “Stinger” w/ 8298 Mount
  • Crosslays: (2) 2” with 1 ½” Swivel
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Hinged Compartment Door
  • 224 cu. ft. of Compartment Space
  • Alco-Lite PEL-24 (24’ 2-Section & PRL-14, 14’ Roof & 10’ Folding)
  • Ladder Chute

OPTIONAL EQUIPMENT:

  • 12” Bumper Extension
  • Federal Q2B Siren
  • 6KW Smart Power Generator
  • Hannay Electric Cord Reel, 150’ (1)
  • David Clark Intercom System, 4-Position
  • Ziamatic SAC-44 Folding Wheel Chocks
