Delivery Date:
07/21/2022
Department Name:
Doyle Fire District
Department City / State:
Buffalo, NY
Truck Type:
Sutphen Corporation – HS #7010
Dealer – Herb Fire
WHEELBASE: 242 ½”
TRAVEL HEIGHT: 10’ – 1”
TRAVEL LENGTH: 37’ – 3”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 15” Raised Roof
- Four-Door, Eight-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 31,000 lbs
- Engine: Cummins L 9, 450HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1750 GPM 6” Suction, Single Stage Pump
- Discharges: (1) 3” Left, (1) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 3” Pipe to Right Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 2 ½” Front Bumper
- Speedlays: (1) 1 ½” Speedlays, (1) 2 ½” Speedlays
- 1000-Gallon Water Tank
- 50-Gallon Foam Tank
- Foam System: Hale Smartfoam 3.3
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-Up Compartment Doors, Satin Finish
- Over 383 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: (1) 24’ 2-section, (1) PRL-14 14’ Roof, (1) 10’ Folding
- Body: PA-18 56/53 Chute & Modified DBL Hatch
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: Inview 360HD w/ Built-In DVR
- Hannay Electric Cord Reel, 175’ (1)
- Generator: 8KW Harrison
- Whelen Freedom 72” LED (18 Modules) Lightbar
- Whelen M9 Red and Blue LED
- FireTech 3-Piece 12V Brow Light
- FireTech 12V LED Scene Light
- FR Spectra 240V Tele Lights
