Delivery Date:
07/29/2020
Department Name:
Canton Fire Department
Department City / State:
Canton, OH
Truck Type:
Sutphen Corporation – HS #6544
Dealer – Herb Fire
WHEELBASE: 196”
TRAVEL HEIGHT: 9’ – 9”
TRAVEL LENGTH: 32’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1,500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (2) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” Valve-Piping w/ 1 ½” Swivel
- 1,000-Gallon Water Tank
- 30-Gallon Foam Tank
BODY: Sutphen
- AMDOR Roll-Up Compartment Doors
- 246 Cu. Ft. Base Compartment Space
- Ladder Package (24’ 2-Section, 14’ Roof and 10’ Folding)
- Body: G9-Alum 40/51
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview
- 4 Bottle Compartments
- FRC Spectra LED Brow Light
- Whelen Freedom IV 72” Lightbar
- FRC Spectra Telelights
- Whelen 900 Warning Lights
- Whelen Ion LED Red Lights
