Delivery Date:
06/16/2021
Department Name:
Delta Township Fire Department
Department City / State:
Lansing, MI
Truck Type:
Sutphen Corporation – HS #6820
Dealer – Apollo Fire Equipment
WHEELBASE: 196”
TRAVEL HEIGHT: 9’ – 11”
TRAVEL LENGTH: 32′ – 8”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 450HP
- Alternator: C.E. Niehoff 360 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- Hale XS QMAX-1500 Single Stage
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (1) 2 ½”
- Speedlay: (2) 2” w/ Swivels & Aluminum Lift-Out Trays
- 1,000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: Hale Smartfoam 2.1A
BODY: Sutphen
- Hinged Aluminum Compartment Doors
- Over 290 cu. ft. Total Compartment Space
- Alco-Lite Ladder Compliment: PEL-2 24’ 2-Section & PRL-14 14’ Roof, 10’ Folding
- Body: G9 – Alum 40/51 Ladders Through Tank
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel Bumper Painted
- Federal Q2B Siren, Grille Mount
- Camera System: Safety Vision SV-CLCD0-70
- Intercom: David Clark 5 Position
- Whelen Freedom LED Lightbar w/ Opticom
- (2) Whelen PFH2 LED Brow Lights
- Whelen Pioneer PFH2 Recessed
- Whelen LED Traffic Advisor
