Delivery Date:
05/10/2022
Department Name:
Coraopolis Fire Department
Department City / State:
Coraopolis, PA
Truck Type:
Sutphen Corporation – HS #6947
Dealer – F.A.S.T. of the Allegheny Mountains
WHEELBASE: 212’ – 0 ½”
TRAVEL HEIGHT: 9’ – 11”
TRAVEL LENGTH: 33′ – 10 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 56” Cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins X 12, 500 HP
- Alternator: Leece Neville 420 AMP
- Transmission: Allison Gen 5, EVS4000
PUMP: Hale
- QMAX-1500 GPM Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- Crosslay: (2) 2” w/ 1 ½” Swivel
- 500-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll Up Compartment Doors
- Over 400 cu. ft. Total Compartment Space
- Alco-Lite Ladder Compliment: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: S-8 Aluminum 56/53 Ladder through Tank & Double Hatch
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Camera System: FRC Inview, 360 Camera
- Generator: Smart Power 6KW
- Hannay Electric Cord Reel, 100’ (2)
- Whelen Freedom IV 72” LED Lightbar
- FireTech 3-Piece 72” LED Brow Light
- FRC Spectra Tele Lights
- Spectra 12V Scene Light
- Whelen M9V2 Lights
